1 PIECE STAINLESS STEEL BALL VALVE
- Port size
- 1/4”~3” 1000 W.O.G
- Pressure
- 1000PSI
- Structure
- ONE PIECE BODY
- Medium
- Water,steam,oil,gas
- Temperature
- -20~150ºC
- Body material
- STAINLESS STEEL
- Connection
- Threads Conform to ASME B1.20.1(NPT)
- Feature
- China Threaded End Ball Valve manufacturing
Product Description
Stainless steel one-piece ball valve is also called quick opening ball valve, internal thread ball valve and small ball valve. It is applicable to air, steam, water, gas, petroleum and petrochemical products, corrosive media, etc. the stainless steel one-piece ball valve is applicable to various pipelines with PN1.0 ~ 4.0Mpa, working temperature of -29 ~ 180 ℃ (the sealing ring is reinforced polytetrafluoroethylene) or -29 ~ 300 ℃ (the sealing ring is para polyphenyl). It is used to cut off or connect the media in the pipeline. Different materials are selected, which can be applied to water, steam, oil, nitric acid Acetic acid and other media.
Structural Features
Product name: Stainless Steel Floating Ball Valve
Size: 1/4" -3" (DN8-DN80)
Material: SS201, SS304, SS316(CF8, CF8M)
Pressure: 1000psi, PN16
Suitable medium: water, oil, air and some corrosive liquid etc(WOG)
Temperature Range: -20-250 degree C
Connection: F/F threaded
Type of thread: NPT, BSPT, BSP, PT, DIN2999 ETC
Sealing: PTFE, RPTFE, PPL ETC
Materials of main parts
|
No |
Part |
Matarial |
|
1 |
BODY |
ASTM A351 CF8, CF8M |
|
2 |
CAP |
PTFE/RPTFE |
|
3 |
BALL |
SS304, SS316 |
|
4 |
NUT |
SS304, SS316 |
|
5 |
STEM |
SS304, SS316 |
|
6 |
PACKING |
PTFE |
|
7 |
GLAND |
SS304 |
|
8 |
HANDLE |
SS201+PVC |
|
9 |
GASKET |
SS304 |
|
10 |
NUT |
SS304 |
Dimensions(mm)
|
Size |
Port |
Pressure |
d |
L |
H |
E |
HEX |
|
1/4" |
RP |
1000PSI |
5 |
39 |
31 |
70 |
17 |
|
3/8" |
RP |
1000PSI |
7 |
44 |
36 |
80 |
21 |
|
1/2" |
RP |
1000PSI |
9 |
59 |
42 |
95 |
25 |
|
3/4" |
RP |
1000PSI |
12.5 |
60 |
45 |
95 |
32 |
|
1" |
RP |
1000PSI |
15 |
72 |
54 |
110 |
38 |
|
1-1/4" |
RP |
1000PSI |
20 |
77 |
59 |
110 |
48 |
|
1-1/2" |
RP |
1000PSI |
25 |
84 |
63 |
150 |
53 |
|
2" |
RP |
1000PSI |
32 |
100 |
70 |
150 |
66 |
|
2-1/2" |
RP |
1000PSI |
38 |
120 |
95 |
200 |
82 |
|
3" |
RP |
1000PSI |
48 |
142 |
103 |
200 |
96 |
